LAMBDABOARD is a flexible faced Polyisocyanurate (PIR) insulation board made on a continuous laminator. The polyisocyanurate cored insulation uses a hydrocarbon-based blowing agent which has zero Ozone Depletion Potential (ODP) and complies with Kyoto Protocol regarding Global Warming Potential (GWP).
LAMBDABOARD offers you the best possible solution for your insulation requirement, compared to similar products in the market. LAMBDABOARD is also the only product that offers you LTTR Long Term Thermal Resistance.
When it comes to fire performance, LAMBDABOARD is a Thermoset material and unlike Thermoplastic's, it won’t soften melt or drip when exposed to flames.
Moisture and wind resistant
Thermoset, does not melt, drip or spread flame
Environmentally friendly & recyclable
High compressive strength
Aesthetically pleasing
Reduces energy usage in a building
Superior long-term R-value
The right choice for intelligent organs
In a bid to remain faithful to its mantra, "Take control of your energy costs", Rigifoam recently renewed its commitment to the supply of insulation capable of reducing operational heating and cooling costs resulting in positive environmental and climate change consequences. Its launch product, LAMBDABOARD, is a unique solution to the current energy crisis.
LAMBDABOARD has the highest R-value per 25mm thickness, therefore the design U-value of the insulation system can be achieved with a minimum thickness. This in turn allows the overall footprint of the building to decrease and reduces the cost of construction.
Installing Lambdaboard will have positive impact on the HAVC system required, reducing the requirements for over engineered systems, thus having an effect on energy consumption required to run the HAVC system. Putting money back in your pocket.
| Lambdaboard (R-Value m2 K/W) | XPS | EPS (16/kg per m3) | Bulk Fibrous (12/kg per m3) |
|---|---|---|---|
| 25mm (1.04) | 35mm | 40mm | 40mm |
| 30mm (1.25) | 40mm | 50mm | 50mm |
| 40mm (1.67) | 50mm | 60mm | 65mm |
| 50mm (2.08) | 70mm (30mm + 40mm boards) | 80mm | 80mm |
| 60mm (2.50) | 80mm | 100mm | 100mm |
| 70mm (2.92) | 90mm (40mm + 50mm boards) | 120mm | 120mm |
| 80mm (3.33) | 100mm (50mm + 50mm boards) | 130mm | 135mm |
| 90mm (3.75) | 110mm (80mm + 30mm boards) | 150mm | Cannot compete |
| 100mm (4.17) | 125mm (60mm + 65mm boards) | 170mm (80mm + 90mm boards) | Cannot compete |
* when using a double layer board, fire compliance is comprised, the labour costs to install the boards are also doubled. *
Equivalent thickness comparing R-Values.
Spec your project here
With a rational design
Thickness: 25 mm to 100 mm
Width: 1220 mm
Length: Cut to size Minimum: 1350 mm
On cavity wall and under screed installations
-30°C - 120°C
Based on a rational design using BISMAC software. You can now alter the insulation thickness to determine not only the temperature difference but also the energy saving you can expect. Contact our rational design department to assist you with your calculations and savings. These temperature are based on no HVAC installed.
Lambdaboard Thickness
0 mm
Actual outside temperature
31° C
Calculated inside temperature
Energy usage
Energy savings
The regulations were designed to counter act the dramatic climate change and the degradation of the planet. The South African Government promulgated the SANS 10400 XA building codes, in order to reduce greenhouse emissions These regulations are designed to reduce energy usage and pollution in the built environment.
Lambdaboard has a proven R-Value and a Long-Term Thermal Resistance (LTTR) and will outlive the life span of the building, reducing the future building envelope’s energy consumption and demand, compared to similar thermoplastic products in the market.
Lambdaboard is a member of PIMA (Polyisocyanurate Manufactures Association) with has a proven track record in LTTR and sustainability.
Lambdaboard provides 30% saving energy consumption. 70% of heat loss can be found in the roof of a structure. Lambdaboard can reduce this by 100% so that no heat is lost via the roof structure.
Reference Building as per SANS 10400XA
Rational Design Building using Lambdaboard
